Evinrude SPL trim gauge wiring diagram. November 23rd, , AM.

Hi can anyone tell me how the trim gauge is wired on my can someone please tell me what wires go to which terminals on an omc trim gauge.I can see terminals at 11 0clock 1 oclock 3 oclock and 5. I, G, and S terminals on the gauge??

Here is your wiring diagram http://www. wiringall.com /wiringall.com “Experience is. Do this, pull the gauge out, and leave all of the wires hooked up to it except for Here is a link to the parts diagram for your sterndrive.

Jeff’s OMC Sensor Arm. I have a Johnson 40HP outboard with trim & tilt(J40TLCE). I recently purchased a trim gauge but it didn’t come with a wiring diagram.On some OMC TRIM gauges, for example the one I have, this direction is reversed, and the resting or no-current position of the gauge is at the right hand side.

When more current flows the pointer moves to . Find great deals on eBay for omc trim gauge.

Shop with confidence. The best part is you do not need a wiring diagram.

All you have to do is hook up the three wires that are under your console in the keyswitch wiring harness, black wire to ground terminal on the trim gauge, purple to the Power or ” I ” terminal, and white-tan to the sender terminal. The way the trim gauge is fairly simple, it all works on a resistance to ground principle.

The trim sending unit on the side of the gimbal ring is a variable resistor. Do this, pull the gauge out, and leave all of the wires hooked up to it except for the sender (The S terminal wire) wire.
